Noble Standard Rail Panels Overview

Overview

Noble Standard Rail Panels are a pre-fabricated steel fencing system designed for smooth installation and uniform appearance.

The custom panel design allows for flexibility in layout while maintaining consistent rail spacing and aesthetics across arenas, paddocks, and livestock areas.

These durable panels are available in 3, 4, 5, 6, or 7-rail designs with custom lengths, making them an excellent choice for anything from simple barn paddocks to complex event centers, rodeo arenas, or equine facilities.

Read More

Panels

Standard Panels are constructed from 15 gauge, 1-⅝”, high-tensile galvanized steel tubing. Each panel passes Noble’s rigorous fit and finish standards.

Top corners are squared instead of rounded to avoid the risk of an animal hanging a leg. Joints are notched and fully welded.

Panels come with clamps to attach to each other or to matching durable posts.

You can order robust 1-⅞” panels or check out our solid panels and 6’ tall ultra-mesh horse panels here.

Read More
Noble Standard Rail Panels
Noble Standard Rail Panel Posts and Mounting

Posts and Mounting

Noble Standard Rail Panels are designed to mount to galvanized steel posts using sturdy clamps.

Posts are typically set in concrete to provide stability and long-term performance.

For a portable system without posts, upgrade to the Noble pin system instead of clamps for faster assembly and disassembly.

Read More

Customizations

Noble Standard Rail Panels are available in 3, 4, 5, 6, or 7-rail designs with multiple height options.

Custom lengths can be selected from 4’-20’ long per panel.

Powder coating is available if desired for a premium appearance.

Panels can be paired with matching gates mounted on solid posts set in concrete, or for a free-standing system select bowgates.

Read More
Noble Standard Rail Panel Customizations
Noble Standard Rail Panel Specifications

Specifications

  • Galvanized steel rail panel construction
  • Gatorshield galvanizing
  • 1-⅝” or custom 1-⅞” diameter steel tubing
  • Matching 2-⅜”, 2-⅞”, or 4” diameter posts available depending on application
  • These panels use a durable high-tensile steel for extra strength
  • 15 gauge tubing
  • Multiple heights depending on rail count
  • 3, 4, 5, 6, or 7-rail options
  • Post spacing for permanent applications: 20’ standard
  • Free-standing and portable systems available with no posts
Read More

Best Applications

Noble Standard Rail Panels applications may include but are not limited to:

  • Riding arenas
  • Roping arenas
  • Rodeo arenas
  • Fairground fencing
  • Event centers
  • Barn paddocks
  • Portable stall systems
  • Round pens
  • Complex paddock runs
  • Cattle working pens
  • Horse runs
Read More
Noble Standard Rail Panel Applications
EstimateApproximate Project Cost
This approximate price includes all materials, concrete, and professional installation, but does not include tax, freight/travel, or unusual site conditions (like poor soil or limited access).
PDF
Project Length (Linear Feet) ? Do not include gates in fence length because they will be added separately below.
Project length must be at least 300 feet.
Color
Black
White
Post Spacing
10' Spacing
Number of Rails
Top Rail
2 Rail
3 Rail
4 Rail
Rail Strength ? Standard rails have a 400 lb side pressure rating and heavy rails have a 700 lb side pressure rating.
Standard
Heavy
Add Gates
Wire Mesh ? Add wire mesh for small animals such as dogs, chickens, or goats. Choose black wire for black fences or galvanized/black wire for white fences.
None
Black No-Climb $8.22 / ft
Galv No-Climb $7.35 / ft
Black Chain Link $10.73 / ft
Arena Footing Boards ? Footing boards are mounted at ground level to keep arena footing from escaping under the fence.
None
Standard Boards $16.85 / ft
Heavy Boards $18.42 / ft
Solar Lights
None
½ Posts
All Posts
Was $— $— You save: $—
🏆
Bronze
$25,000+
3%
🏆
Silver
$50,000+
6%
🏆
Gold
$100,000+
9%
🏆
Platinum
$200,000+
12%
Please enter your project length above to proceed.
Still planning your project?

Built by Experienced Ranch Fence Specialists

Decades of hands-on installation experience across private ranches and large-scale agricultural properties.

0
Feet of Buckley Steel Fencing installed
0
Feet of Combined Ranch Rail Fencing

See Projects Built with Buckley Steel Board Fencing

Installed across elite ranches and equestrian facilities.

Ready to Upgrade Your Ranch Fence?

Get a Free Estimate
